CENTURION PHOTON SMART FULL WIRELESS GATE BEAM SET
Photon SMART
CENTURION PHOTON SMART FULL WIRELESS GATE BEAM SET
Free Standard Delivery Australia-wide only
Incudes
- Photon SMART wireless PE - Transmitter
- Photon SMART wireless PE - Receiver
- 4 x AA Alkaline Batteries1
- Manual
- Brochure
Warranty - 01 year manufacturer's warranty (This warranty covers failure due to manufacturer's fault)
Description
Get peace of mind in no time thanks to our award-winning SMART technology. Connecting wirelessly to your CENTSYS SMART solution, Photon SMART wireless PE safety beams give you an automated gate motor system that isn’t just safe, it’s intelligently safe.
- Completely wireless and battery-operated saving time and money
- Compatible with all Smart Gate and Garage door opperators
- Thirty-metre operating range
- Fully ant-proof and weather-resistant enclosure for greater reliability
- Low power consumption throughout the system for greater efficiency
- Elegant slimline construction – only 50mm wide
Features
- Connects wirelessly to your SMART solution – saves time and money
- Pair and align in seconds
- Beautifully styled – adds an air of sophistication to your swing or sliding gate
- Outstanding reliability offering up to 2 years of battery life
- Long range – brings safety to even the widest entrance gates
- Fully sealed unit – prevents insect ingress
- Can be easily added to sites with existing hard-wired beam sets
| Technical Specifications: | |
| Power supply | 2 x AA Alkaline Batteries1 (supplied for each transmitter and receiver) |
| Battery life | >2 years |
| Battery-low indication | Notified via MyCentsys Pro Mobile Application |
| Maximum operating distance | 30m |
| Alignment between beams2 | Automatic – 1m circle @ 10m |
| Maximum Operating Distance Photon SMΔRT Receiver to SMΔRT Controller | 10m |
| Operating temperature | -15°C to +65°C |
| Operating humidity | 0 - 90° (non-condensing) |
| Housing material | ABS |
| Lens material | PC |
| Degree of Protection | IP54 |
| Packaging weight | 200g |
- Only replace with AA Alkaline batteries; do not use rechargeable batteries with this product
- Circular area – assuming parallel surfaces

(PHOTON_smart)
| SKU | PHOTON_smart |
| Brand | CENTSYS |
| Shipping Weight | 0.2750kg |
| Shipping Width | 0.065m |
| Shipping Height | 0.065m |
| Shipping Length | 0.140m |
| Shipping Cubic | 0.000591500m3 |
